Long Stroke, High Force Shaker Series

Part Number Force Peak to Peak Displacement Technical Specs
SD-8360LS4-17/DA-60* 8360 lbs (3800 kgf) 4 Inches (100 mm)

*(Long Stroke also available for 4400/6600/11000/13200/15400 Lbs Force Shakers)



Low Force Shaker Series

Part Number Force Peak to Peak Displacement Technical Specs
SD-220-5/DA-1 220 lbs (100 kgf) 1 inch (25 mm)
SD-440-6/DA-2 440 lbs (200 kgf) 1.5 Inches (38 mm)
SD-660-6/DA-3/ACU751 660 lbs (300 kgf) 1.5 Inches (38 mm)
SD-1518-7/DA-6/ACU402* 1518 lbs (690 kgf) 2 Inches (50 mm)
SD-1510-230M/SPA602HB/ACU402 690 kgf (1,510 lbf) 2 Inches (51 mm)
SD-1510-230M/SPA602LB/ACU402 690 kgf (1,510 lbf) 2 Inches (51 mm)
SD-1510-230M/SPA602MB/ACU402 690 kgf (1,510 lbf) 2 Inches (51 mm)
SD-1510-230M/SPA602SB/ACU402 690 kgf (1,510 lbf) 2 Inches (51 mm)

*(7" and 9" Armature Dia available)



Medium Force Shaker Series

Part Number Force Peak to Peak Displacement Technical Specs
SD-2420-9/DA-10 2420 lbs (1100 kgf) 2 Inches (50 mm)
SD-5280-13/DA-20 5280 lbs (2400 kgf) 2 Inches (50 mm)
SD-8360-13/DA-40 8360 lbs (3800 kgf) 2 Inches (50 mm)
SD-8360LS4-440M/SPA403/ACU153 8360 lbs (3800 kgf) 4 Inches (100mm) intermittent,
3 Inches (75mm) continuous



High Force Shaker Series

Use our Contact Form to request for additional information regarding these shakers.

Part Number Force Peak to Peak Displacement Technical Specs
SD-11000-17/DA-50 11000 lbs (5000 kgf) 2 Inches (50 mm)
SD-11000LS3-445M/SPA503/ACU153 11000 lbs (5000 kgf) 3 Inches (75 mm) intermittent 2.5 Inches (63.5 mm) continuous
SD-13200-17/DA-60 13200 lbs (6000 kgf) 2 Inches (50 mm)



Laboratory Shaker Series

Part Number Force Peak to Peak Displacement Technical Specs
M1600W 200 N Sine Vector (140N Random) .75 Inches (19.2 mm)



Note: In keeping with our commitment to continuous product improvement, the information herein is subject to change.
